High-Precision Paper Fold Endurance Tester – ISO/TAPPI Compliant Folding Strength Test Equipment with Servo Motor Drive

Markenbezeichnung:	HongCe
Modellnummer:	HC-A519-2
MOQ:	1 Satz
Preis:	Negotiatable
Zahlungsbedingungen:	L/C,T/T,D/P
Versorgungsfähigkeit:	10 Stück pro Monat

Einzelheiten

Produkt-Beschreibung

Einzelheiten

Herkunftsort:

China

Zertifizierung:

Third party calibration certificate(cost additional)

Testlast:

4,9 Zoll, 9,8 Zoll, 14,72 N

Probengröße:

15 mm x 150 mm, Probendicke weniger als 1,25 mm

Gesamtabmessungen:

421*357*526MM

Testgeschwindigkeit:

(175 ± 10) U/min (Geschwindigkeit kann beliebig von 0–175 ± 10 U/min eingestellt werden)

Breite des Klappkopfes:

19+1mm

Faltsehnenradius:

0,38+0,02mm; (austauschbar)

Verpackung Informationen:

Sperrholz

Hervorheben:

High-Precision Paper Fold Endurance Tester

ISO/TAPPI Compliant Folding Strength Test Equipment

Servo Motor Drive Paper Testing Machine

Produkt-Beschreibung

Paper Fold Endurance Tester for Packaging and Paper Materials

The Paper Fold Endurance Tester from HongCe is engineered to provide manufacturers, laboratories, and quality-control teams with precise durability assessment of paper materials. This high-precision folding strength test equipment delivers reliable results for packaging paper, printing paper, banknotes, labels, and specialty materials, featuring stable performance, intuitive operation, and compliance with international standards.

Key Features

High Folding Accuracy – Stable mechanism ensures consistent fold angles and tension force
Long Lifespan & Industrial Design – Durable mechanical components built for 24/7 continuous testing
Easy-to-Use Interface – Clear layout and ergonomic operation suitable for all skill levels
Automatic Counting System – Real-time fold cycle tracking with digital display
Wide Material Compatibility – Supports thin paper, kraft paper, coated paper, specialty paper, banknote-grade materials, and more

International Standards Compliance

ISO/TAPPI Paper Folding Endurance Standards
ISO 5626 – Paper — Determination of folding endurance
TAPPI T511 – Folding endurance of paper (MIT-type)
TAPPI T423 – Folding endurance of paper (Schopper method)

Technical Specifications

Specification	Parameter
Drive Method	Servo Motor
Test Load	4.91N, 9.81N, 14.72N
Bending Angle	135°±2° on each side (can be any angle from 135° to 0 to 135°, single-sided and double-sided bending resistance)
Specimen Size	15mm*150mm, specimen thickness less than 1.25mm
Test Speed	(175±10) r/min (speed can be set arbitrarily from 0 to 175±10 r/min)
Folding Head Width	19±1mm
Folding Edge Radius	0.38±0.02mm (replaceable)
Folding Head Gap Distance	0.25mm/0.5mm/0.75mm/1.0mm (other gaps can be customized)
Counter	0~999999 times, automatic stop
Dimensions	421357526mm (LWH)
Display Method	Touchscreen display
Weight	Approximately 30KG
Power Supply	1∮, 220V, 50HZ, 1A
Total Power Consumption	Approximately 500W
Main Test Item	Folding Endurance Test of Paper Fiber Materials

Materials & Products That Can Be Tested

Packaging paper
Book paper & notebook paper
Currency and security paper
Label paper & adhesive paper
Kraft paper & corrugated paper
Specialty technical paper

Testing Capabilities

Folding endurance
Paper fatigue resistance
Bending strength
Paper aging durability performance
Material resistance under cyclic stress

Product Image

Frequently Asked Questions

How long does a typical folding durability test take?

This depends on the paper type and durability rating. Some papers can be tested in minutes, while high-durability materials may take several hours.

Can this machine test very thin paper?

Yes. The adjustable clamping system is designed for thin paper, toilet paper, and lightweight specialty materials.

Does it comply with ISO 5626?

Fully compliant. This tester fully complies with ISO, TAPPI, ASTM, and GB standards.

Is calibration required?

Yes. Calibration ensures data accuracy. Hongce provides calibration guides and optional certified calibration services.

Can I run tests continuously for extended periods?

Yes. This machine is designed for stable 24/7 laboratory operation.

Is special installation required?

No. Simply connect to a power source to begin testing.
